WILA Type 86° Gooseneck Punch – H98mm, R1, 65 Ton/m
This WILA Type 86° gooseneck punch features a 98 mm working height, 50 mm overall width, 8 mm tip width and R1 mm tip radius. Its recessed gooseneck profile provides generous clearance for return flanges, U-shaped parts and previously formed bends. Manufactured from 42CrMo steel and hardened to HRC54±2, it supports a maximum load of 65 ton/m.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
This WILA Type 86° gooseneck punch is designed for sheet metal components that require additional clearance between the upper tool and previously formed flanges. Its deeply recessed body profile allows return flanges, U-shaped channels and box-type components to move past the punch body with a reduced risk of tool-to-workpiece interference.
Compared with a conventional straight press brake punch, the 50 mm-wide gooseneck profile provides significantly more side clearance. This makes the tool especially useful for second and subsequent bends on parts where an existing flange would otherwise collide with the upper tool.
The 86° punch angle is suitable for general air bending and for producing nominal 90° bends while allowing appropriate compensation for material springback. Its R1 mm tip radius provides accurate bend-line control, while the 8 mm tip width offers a practical balance between access to smaller bending areas and structural strength.
With a 98 mm working height and maximum load capacity of 65 ton/m, this gooseneck upper tool is suitable for light- and medium-duty sheet metal forming. It is manufactured from high-strength 42CrMo alloy tool steel and hardened to HRC54±2 for dependable wear resistance, dimensional stability and repeated bending accuracy.
Key Features
- WILA Type gooseneck punch for compatible clamping systems
- Recessed profile provides excellent clearance for formed flanges
- Suitable for U-shaped parts, return bends and box profiles
- 86° punch angle for general air bending and springback compensation
- Compact 98 mm working height
- Wide 50 mm gooseneck profile for increased side clearance
- Narrow 8 mm punch tip for accurate positioning in restricted areas
- R1 mm tip radius for precise bend-line formation
- Maximum load capacity of 65 ton/m
- Manufactured from high-strength 42CrMo alloy steel
- Hardened to HRC54±2 for improved wear resistance
- Precision-machined for accurate and repeatable bending
- Continuous and segmented tool lengths available
- Custom gooseneck profiles and dimensions available
Technical Specifications
| Parameter | Specification |
|---|---|
| Tool Type | WILA Type Press Brake Upper Punch |
| Punch Profile | Gooseneck Punch |
| Working Height (H) | 98 mm |
| Overall Tool Width | 50 mm |
| Upper Clamping Section Width | 20 mm |
| Tip Width | 8 mm |
| Tip Angle (α) | 86° |
| Tip Radius (R) | 1 mm |
| Maximum Load | 65 ton/m |
| Material | 42CrMo |
| Hardness | HRC54±2 |
| Length | Continuous or segmented, customizable |
| Primary Application | Return flanges, U-shaped parts and box bending |
Typical Applications
This WILA Type gooseneck press brake punch is suitable for:
- Bending U-shaped channels and profiles
- Forming return flanges and reverse bends
- Producing box-shaped and tray-shaped sheet metal parts
- Completing second and subsequent bends on pre-formed components
- Bending components with inward-facing flanges
- Avoiding interference between the workpiece and punch body
- Electrical cabinets and control enclosures
- Metal boxes, trays and equipment housings
- HVAC ducts and ventilation components
- Machinery covers and industrial panels
- Stainless steel, mild steel and aluminium sheet fabrication
- CNC hydraulic and servo-electric press brake applications
Actual bend capacity depends on the workpiece material, sheet thickness, bending length, selected lower-die V-opening and forming method. The required bending force must remain within the rated capacities of the punch, lower die and press brake.
Product Details & Manufacturing Quality
The gooseneck punch is manufactured from selected 42CrMo alloy steel, providing a reliable combination of mechanical strength, toughness and fatigue resistance. Its working area is hardened to HRC54±2 to improve resistance to wear and deformation during repeated production.
Precision machining ensures consistent control of the 86° working angle and R1 mm punch-tip radius across the complete tool length. Accurate geometry helps maintain bend-line positioning and consistent forming results in batch production.
The recessed body is designed to increase usable clearance around previously formed flanges. However, the actual clearance available for a specific component depends on the flange height, bend position, workpiece angle and tool segmentation. Customers can provide their component drawings so that the tool profile and bending sequence can be checked before production.
The tool can be supplied as a continuous-length punch or as a segmented set. Segmented tooling provides greater flexibility when producing boxes, trays, narrow profiles and components with complex bending sequences.
Standard & Custom WILA Type Press Brake Tooling
WYS Machinery supplies standard and customized WILA Type gooseneck punches, straight punches, lower dies, adapters and related press brake tooling for compatible clamping systems.
Customers can send us their workpiece drawings, material specifications and required bending profiles. Our technical team provides a free tooling design service and recommends an appropriate punch-and-die combination according to the workpiece geometry, flange clearance, bending sequence and required forming force.
Available customization options include:
- Working height and overall tool width
- Gooseneck depth and clearance profile
- Punch angle and tip radius
- Tip width and load-bearing section
- Continuous or segmented tool lengths
- Customized section arrangements and horn pieces
- Special profiles for U-shaped and box-shaped components
- Surface blackening and protective coating
- Tooling solutions for complex or restricted-clearance bends
This product is manufactured as WILA Type compatible press brake tooling. It is not presented as an original WILA-manufactured product and does not imply official affiliation, authorization or endorsement by WILA.
